Big Block Mopar Tri-Y Under Chassis Headers

Regular price $739.00 $0.00 Unit price per
Shipping calculated at checkout.

Our Big Block Mopar Tri-Y Headers give you high-flow header performance and a custom fit that means you don't have to sacrifice your power steering. Fits all Big Block engines - 361, 383, 400, 413, 426 Wedge, and 440.  Also fits great with most aftermarket aluminum heads with angled plugs.  Retain exhaust studs in the heads, so no more breaking into a water jackets!  Plus, unlike most headers, they don't capture the starter.  Specifically designed for your application, they install quickly and painlessly, even with the engine in place. Fits with manual or power steering, and automatic transmission.  Available in raw steel or matte silver ceramic coating.  Photos showing other coatings are for reference only and are NOT available.  Some vehicle may require motor mount shimming due to poor factory tolerances.  If needed we have a shim pack available HERE.  Made in the USA!

Installation Instructions

Fits all vehicles below:

'67 & up A-Body,
'62 & up B-Body,
'65 & up C-Body,
'70-74 E-Body,
'73 & up F, M and J-Body.

Designed for street use and light competition - retains all your low-end torque.

Header Flange Pipes:  We have fixed flange head pipes available HERE.  For more adjustability; we have ball-joint flange head pipes available HERE.

4-speed customers: Clutch Z-bar interferes with the driverside header. You can use a hydraulic clutch system or our headers can be modified to fit a 4-speed transmission.

'65 C-Body applications: Headers do not work with 413, 440 or 426 wedge. In some cases, the automatic kick down bellcrank may hit the flange and need to be narrowed.

'66-73 C-Body applications: The 440 may require shims on the passenger side motor mount. In some cases, the automatic kickdown bellcrank may hit the flange and need to be narrowed.

'77-79 Magnum and Cordoba (B-body) with column shift: The shift linkage may be low enough to interfere with the header. TTI's offset shaft can solve this problem.

If your original studs are damaged or missing, we have replacement stud kits available here: R/RB Header Stud Kit

If you need a Mini Starter, we also have those available here: Mopar Mini Starter

Part Number: H - Raw Steel

Part Number: HCE - Ceramic Coated

Customer Reviews

Based on 25 reviews
84%
(21)
12%
(3)
0%
(0)
4%
(1)
0%
(0)
E
Ethel Nock
Headers

Wrong size

Hi Ethel,
We're sorry you felt the need to poorly rate the product. We responded to both return requests, e-mail and phone, with no response. We only make one size Big Block Tri-Y car header. ‍♂️

L
Lance Wolfe

I wish I knew about these before I bought a 500.00 dollar set of headers that didn't fit, and then a 400.00 dollar set of manifolds that didn't fit. The header I got from you fit perfectly thank you all

M
Mark Pozzi
Header install

I stalled headers on a 383 powered 73 charger.
Install was super quick and easy, passenger side dropped protein from top, driver only had to remove
plugs and starter, went in from bottom and bolted rite down. Look real kool!

M
Mikel Wells

Big Block Mopar Tri-Y Under Chassis Headers

P
Peter Rutkauskas
They’re nice!

Small 2 1/2” collectors but they fit in this 69 Dodge Dart (383) with power steering,power brakes and automatic transmission. Some motor mount shimming to clear steering bars,tie rod on right side but all is well. Well made product. I highly recommend this product.
